| 3.45mm F3.0 1/4" 5MP M8x0.35 Small Lens (OV5640 Lens) |
|
This 3.45mm 1/4" Wide Angle M8 Small Lens is newly developed, compatible with 5MP 1/4" VGA CMOS Sensor. Cost-effective solution and steady quality control for volumn production.
|
 |
|
|
Model No.
|
L1284
|
|
Focal Length
|
3.45mm
|
|
Relative Aperture
|
F3.0
|
|
Sensor Size
|
1/4" OV5640
|
|
Flange Back Focal Length
|
3.2mm
|
|
Angle of View
|
106°x85°x63.75°
|
|
Min. Operation Distance
|
0.2m
|
|
Mount Size
|
M8x0.35
|
|
TTL
|
14.6mm
|
|
Optical Distortion
|
<-48% in the edges
|
|
Construction
|
Metal, Glass and Plastics
|
|
Optical Filters (optional)
|
650nm IR Cutoff Filters
|
|
|
|
| |
|
More and more applications are requiring higher resolution for better image functions, to help the systems reach the expected performance. Lenoptec are trying to develop the cost-effective optical products to help our customers' project reach the success.
|
|
|
